物理化学学报 >> 2016, Vol. 32 >> Issue (2): 536-542.doi: 10.3866/PKU.WHXB201511103

论文 上一篇    下一篇

RE-B共掺杂片层TiO2的合成及其光催化性能

王瑞芬1,2,*(),王福明2,宋金玲1,安胜利1,2,王鑫1

  1. 1 内蒙古科技大学材料与冶金学院, 内蒙古包头 014010
    2 北京科技大学冶金与生态工程学院, 北京 100083
  • 收稿日期:2015-07-07 发布日期:2016-01-30
  • 通讯作者: 王瑞芬 E-mail:jery19810528@126.com
  • 基金资助:
    国家自然科学基金(21407084);内蒙古自然科学基金(2015MS0571);内蒙古自治区教育厅高等学校基金项目(NJZY13141)

Synthesis and Photocatalytic Activities of Rare Earth-Boron Co-Doped Slice Layer TiO2

Rui-Fen WANG1,2,*(),Fu-Ming WANG2,Jin-Ling SONG1,Sheng-Li AN1,2,Xin WANG1

  1. 1 School of Materials and Metallurgy, Inner Mongolia University of Science and Technology, Baotou 014010, Inner Mongolia Autonomous Region, P. R. China
    2 School of Metallurgical and Ecological Engineering, University of Science and Technology Beijing, Beijing 100083, P. R. China
  • Received:2015-07-07 Published:2016-01-30
  • Contact: Rui-Fen WANG E-mail:jery19810528@126.com
  • Supported by:
    the National Natural Science Foundation of China(21407084);Natural Science Foundation of Inner Mongolia, China(2015MS0571);Higher School Foundation from Education Department of Inner Mongolia, China(NJZY13141)

摘要:

采用溶胶-凝胶法,利用钛酸四丁酯、硝酸镧、硝酸铈和硼酸为原料,对TiO2光催化剂进行稀土-B(RE-B)的共掺杂改性制备和性能研究。采用X-射线衍射法(XRD)、冷场发射扫描电子显微镜(SEM)、X射线光电子能谱(XPS)、紫外-可见吸收(UV-Vis)光谱和荧光(PL)光谱对制得样品的相组成、表面形貌结构、表面元素组成、光响应范围及带隙能和电子-空穴的复合情况进行了初步分析。结果表明,所制掺杂TiO2的组成均为锐钛矿型,掺杂使晶格发生了较大畸变,且细晶粒由未掺杂的27 nm减小到RE-B-TiO2的10 nm,形貌为片层状不规则堆放状态存在。XPS结果表明掺杂元素有效进入二氧化钛, PL谱显示共掺杂可有效延长光催化剂的载流子寿命。掺杂后吸收边均红移, La-B-TiO2由TiO2的405 nm移动到466 nm,相应地禁带宽度减小了0.4 eV。光催化实验表明:2 h内降解亚甲基蓝(MB)时掺杂能够同时提高紫外和可见光下二氧化钛的光催化效率,而共掺杂的降解效果又优于单掺杂, La-B-TiO2紫外光下的降解率达到80.67%,为同等条件下纯TiO2的2.7倍,可见光下的降解率为74.78%。

关键词: 溶胶-凝胶法, 稀土-B共掺杂, TiO2, 亚甲基蓝, 光降解

Abstract:

Rare earth (RE) and B co-doped (RE-B) nano-TiO2 photocatalysts were prepared through a sol-gel method using tetrabutyl titanate, lanthanum nitrate, cerous nitrate, and boric acid. The phase constitution, surface morphology, surface elemental compositions, light responsivity, the band gap and the composite of the electronic hole of catalysts were characterized by X-ray diffraction (XRD), scanning electron microscopy (SEM), X-ray photoelectron spectroscopy (XPS), photoluminescence (PL) and ultraviolet-visible spectroscopy (UV-Vis). The results show that all the doped products were anatase TiO2, and RE-B doping generates large lattice distortion and had the function of refining the grain, with the grain size decreasing from 27 nm (TiO2) to 10 nm (La-B-TiO2). The doped TiO2 was flake structure and piled up irregularly. Co-doping enhanced the absorption in the visible region and narrowed the band gap simultaneously. The absorption edge of La-B-TiO2 moved from 405 nm to 466 nm, and the band gap decreased 0.4 eV correspondingly. XPS results show that the doping elements have effectively doped into the titanium dioxide, and PL spectra show that the co-doping can effectively extend the life of the carrier. The photocatalytic activities of the samples were estimated by degrading methylene blue (MB) under visible and ultraviolet light irradiation for 2 h, and show much improved catalytic activity compared to un-doped TiO2. The degradation rate of MB using La/B-TiO2 was 80.67% under ultraviolet light, which is about 2.7 times that of un-doped TiO2, and 74.78 % under visible light.

Key words: Sol-gel method, RE-B co-doping, TiO2, MB, Photo-degradation

MSC2000:

  • O643.3
