Acta Phys. -Chim. Sin. ›› 2021, Vol. 37 ›› Issue (6): 2010059.doi: 10.3866/PKU.WHXB202010059

Special Issue: Design and Fabrication of Advanced Photocatalyst

• ARTICLE • Previous Articles     Next Articles

Constructing 1D/2D Schottky-Based Heterojunctions between Mn0.2Cd0.8S Nanorods and Ti3C2 Nanosheets for Boosted Photocatalytic H2 Evolution

Zhimin Jiang1, Qing Chen2, Qiaoqing Zheng2, Rongchen Shen1, Peng Zhang3,*(), Xin Li1,*()

  1. 1 Key Laboratory of Energy Plants Resource and Utilization, Ministry of Agriculture and Rural Affairs, College of Forestry and Landscape Architecture, South China Agricultural University, Guangzhou 510642, China
    2 College of Materials and Energy, South China Agricultural University, Guangzhou 510642, China
    3 State Center for International Cooperation on Designer Low-Carbon & Environmental Materials (CDLCEM), School of Materials Science and Engineering, Zhengzhou University, Zhengzhou 450001, China
  • Received:2020-10-27 Accepted:2020-12-01 Published:2020-12-04
  • Contact: Peng Zhang,Xin Li;
  • About author:Email:; Tel.: +86-20-85285596 (X.L.)
    Email:; +86-0371-67739798 (P.Z.)
  • Supported by:
    the National Natural Science Foundation of China(51672089);the National Natural Science Foundation of China(51972287);the National Natural Science Foundation of China(51502269);Special Funding on Applied Science and Technology in Guangdong, China(2017B020238005);the Ding Ying Talent Project of South China Agricultural University


Sustainable photocatalytic H2 evolution has attracted extensive attention in recent years because it can address both energy shortage and environmental pollution issues. In particular, metal sulfide solid-solution photocatalysts have been widely applied in photocatalytic hydrogen generation owing to their excellent light harvesting properties, narrow enough band gap, and suitable redox potentials of conduction and valance bands. However, it is still challenging to develop low-cost and high-efficiency sulfide solid-solution photocatalysts for practical photocatalytic hydrogen evolution. Recently, 1D MnxCd1-xS nanostructures have shown superior light absorption, charge separation, and H2-evolution activity owing to their shortened diffusion pathway of carriers and high length-to-diameter ratios. Thus, 1D MnxCd1-xS nanostructures have been applied in photocatalytic H2 evolution. However, a single MnxCd1-xS photocatalyst still has some disadvantages for photocatalytic H2 evolution, such as the rapid recombination of photogenerated electron-hole pairs and low quantum efficiency. Herein, to further boost the separation of photogenerated charge carriers and H2-evolution kinetics, an in situ solvothermal method was used to synthesize the 1D/2D Schottky-based heterojunctions between the Mn0.2Cd0.8S nanorods (MCS NRs) and Ti3C2 MXene nanosheets (NSs). Furthermore, various characterization methods have been used to investigate the crucial roles and underlying mechanisms of metallic Ti3C2 MXene NSs in boosting the photocatalytic H2 evolution over the Mn0.2Cd0.8S nanorods. X-ray Diffraction (XRD), Transmission Electron Microscope (TEM), High Resolution Transmission Electron Microscopy (HRTEM), element mapping images, and X-ray Photoelectron Spectroscopy (XPS) results clearly demonstrate that hybrid low-cost Schottky-based heterojunctions have been successfully constructed for practical applications in photocatalytic H2 evolution. Additionally, the photocatalytic hydrogen evolution reaction (HER) was also carried out in a mixed solution of Na2SO3 and Na2S using as the sacrificial agents. The highest hydrogen evolution rate of the optimized 1D/2D Schottky-based heterojunction is 15.73 mmol·g-1·h-1, which is 6.72 times higher than that of pure MCS NRs (2.34 mmol·g-1·h-1). An apparent quantum efficiency of 19.6% was achieved at 420 nm. The stability measurements of the binary photocatalysts confirmed their excellent photocatalytic stability for practical applications. More interestingly, the UV-Vis diffuse reflection spectra, photoluminescence (PL) spectrum, transient photocurrent responses, and Electrochemical Impedance Spectroscopy (EIS) Nyquist plots clearly confirmed the promoted charge separation between the MCS NRs and Ti3C2 MXene NSs. The linear sweep voltammetry also showed that the loading of MXene cocatalysts could greatly decrease the overpotential of pure MCS NRs, suggesting that the 2D Ti3C2 NSs could act as an electronic conductive bridge to improve the H2-evolution kinetics. In summary, these results show that the 2D/1D hybrid Schottky-based heterojunctions between metallic Ti3C2 MXene NSs and MCS NRs can not only improve the separation of photogenerated electrons and holes but also decrease the H2-evolution overpotential, thus resulting in significantly enhanced photocatalytic H2 generation. We believe that this study will inspire new ideas for constructing low-cost Schottky-based heterojunctions for practical applications in photocatalytic H2 evolution.

Key words: Photocatalytic hydrogen evolution, 1D Mn0.2Cd0.8S nanorods, Ti3C2 MXene NSs, 2D/1D Schottky-based heterojunctions, Solar fuel
