CH2BrCl在265 nm光解产生的氯甲基自由基的振动内能

doi:10.3866/PKU.WHXB201203061

Abstract

Abstract: Photodissociation of CH₂BrCl was investigated around 265 nm using resonance-enhanced multiphoton ionization technique combined with velocity map ion-imaging detection. The ion images of Br (²P_1/2) and Br (²P_3/2) were analyzed to obtain the corresponding velocity distributions and total translational energy distributions. Using an impulsive model invoking angular momentum conservation, the vibrational internal energy distributions of chloromethyl radical (·CH₂Cl) formed by the photodissociation of CH₂BrCl, were derived from the total translational energy distributions. In the CH₂BrCl+hv→Br (²P_1/2)+CH₂Cl channel, v₄, v₃+v₄, v₂+v₄ and v₂+v₆ vibrational modes were found to be excited in the radical; while in the CH₂BrCl+hv→ Br (²P_3/2)+CH₂Cl channel, the excited vibrational modes were v₂+v₆, v₁+v₃, v₂+v₅, v₂+v₃+v₅, and v₁+v₅. The results further implied that, following absorption of one photon by the parent molecule CH₂BrCl, other vibrational modes besides v₅ (CBr stretch) mode, such as v₇ (CH₂ a-stretch) mode, are excited in the parent molecule.

Key words: CH₂BrCl, Photodissociation, Velocity map ion-imaging, Impulsive model invoking angular momentum conservation, Vibrational internal energy distribution

ZHANG Xiu, WU Dong, TANG Bi-Feng. Vibrational Internal Energy of Chloromethyl Radical Formed by the Photodissociation of CH₂BrCl at 265 nm[J]. Acta Phys. -Chim. Sin. 2012, 28(05), 1045-1053. doi: 10.3866/PKU.WHXB201203061

References

(1) Barrie, L. A.; Bottenheim, J. W.; Schnell, R. C.; Crutzen, P. J.; Rasamussen, R. A. Nature 1988, 334, 138.

(2) Anderson, J. G.; Toohey, D. W.; Brune, W. H. Science 1991, 251, 39.

(3) Foster, K. L.; Plastridge, R. A.; Bottenheim, J. W.; Shepso, P. B.; Finlayson-Pitts, B.J.; Spicer, C. W. Science 2001, 291, 471.

(4) Zhu, R.; Tang, B.; Zhang, X.; Zhang, B. J. Phys. Chem. A 2010, 114 (21), 6188.

(5) Niu, M. L.; Song, L.; Tang, X. F,; Zhou, X. G.; Liu, S. L.; Liu, F. Y.; Shan, X. B.; Sheng, L. S. Acta Phys. -Chim. Sin. 2011, 27, 1797. [牛铭理, 宋磊, 唐小锋, 周晓国, 刘世林, 刘付轶, 单晓斌, 盛六四. 物理化学学报, 2011, 27, 1797.]
(6) Gougousi, T.; Samartzis, P.C.; Kitsopoulos, T.N. J. Chem. Phys. 1998, 108, 5742.

(7) Liu, Y. Z.; Qin, C. C.; Zhang, S.; Wang, Y. M.; Zhang, B. Acta Phys. -Chim. Sin. 2011, 27, 965. [刘玉柱, 秦朝朝, 张嵩, 王艳梅, 张冰. 物理化学学报, 2011, 27, 965.]
(8) Zhang, F.; Wang, Y. M.; Zhang, B.; Feng, W. L. Acta Phys. -Chim. Sin. 2010, 26, 1903. [张锋, 王艳梅, 张冰, 冯文林. 物理化学学报, 2010, 26, 1903.]
(9) Zhang, C. H.; Zhang, Y.; Zhang, S.; Zhang, B. Acta Phys. -Chim. Sin. 2009, 25, 1708. [张昌华, 张延, 张嵩, 张冰. 物理化学学报, 2009, 25, 1708.]
(10) Cao, Z. Z.; Zhang, C. H.; Wang, Y. M.; Zhang, F.; Hua, L. Q.; Zhang, B. Acta Phys. -Chim. Sin. 2009, 25, 423. [曹振洲张昌华王艳梅张锋华林强张冰. 物理化学学报, 2009, 25, 423.]
(11) Rubio-Lago, L.; Rodríguez, J. D.; García-Vela, A.; González, M. G.; Amaral, G. A.; Bañares, L. Phys. Chem. Chem. Phys. 2011, 13, 8186.
(12) Sage, A, G.; Oliver, T. A. A.; Murdock, D.; Crow, M. B.; Ritchie, G. A. D.; Harvey, J. N.; Ashfold, M. N. R. Phys. Chem. Chem. Phys. 2011, 13, 8075.
(13) Song, L.; Yu, F.; Wu, L. X.; Zhou, X. G.; Liu, S. L. Acta Phys. -Chim. Sin. 2011, 27, 801. [宋磊, 于锋, 吴琍霞, 周晓国, 刘世林. 物理化学学报, 2011, 27, 801.]
(14) Eppink, A. T. J. B.; Parker. D. H. Rev. Sci. Instrum. 1997, 68(9), 3477.
(15) Lin, J. J.; Zhou, J.; Shiu, W,; Liu K. Rev. Sci. Instrum. 2003, 74(4), 2495.
(16) Townsend, D.; Minitti, M. P.; Suits A. G. Rev. Sci. Instrum. 2003, 74(4), 2530.
(17) Chen, Z.; Liu, F.; Jiang, B.; Yang, X.; Parker. D. H. J. Phys. Chem. Lett. 2010, 1, 1861.

(18) Li, J.; Zhang, C.; Zhang, Q.; Chen, Y.; Huang, C.; Yang. X. J. Chem. Phys. 2011, 135, 116102.

(19) Tang, X.; Zhou, X.; Wu, M.; Liu, S.; Liu, F.; Shan, X.; Sheng. L. J. Chem. Phys. 2012, 136, 034304.

(20) Ratliff, B. J.; Womack, C. C.; Tang, X. N.; Landau, W. L.; Butler,L. J.; Szpunar, D. E. J. Phys. Chem. A 2010, 114, 4934.

(21) Womack, C. C.; Fang, W. H.; Straus, Daniel B.; Butler, L. J. J. Phys. Chem. A 2010, 114, 13005.

(22) Ratliff, B. J.; Alligood, B. W.; Butler, L. J.; Lee, S.-H.; Lin, J. J.-M. J. Phys. Chem. A 2011, 115, 9097.

(23) Womack, C. C.; Booth, R. S.; Brynteson, M. D.; Butler, L. J.; Szpunar, D. J. Phys. Chem. A 2011, 115, 14559.

(24) Tzeng, W. B.; Lee, Y. R.; Lin, S. M. Chem. Phys. Lett. 1994, 227, 467.

(25) Cadman, P.; Simsons, J.P. Trans. Faraday Soc. 1966, 62, 631.

(26) Doucet, J.; Gilbert, R.; Sauvageau, P.; Sandorfy, C. J. Chem. Phys. 1975, 62, 366.

(27) McGivern, W. S.; Li, T.; Zou, P.; North, S. W. J. Chem. Phys. 1999, 111, 5771.

(28) Zou, P.; McGivern, W. S.; North, S. W. Phys. Chem. Chem. Phys. 2000, 2, 3785.
(29) Lee, S. H.; Jung, Y. J.; Jung, K. H. Chem. Phys. 2000, 260, 143.

(30) Zhou, J. G.; Lau, K. C.; Hassanein, E.; Xu, H. F.; Tian, S. X.; Jones, B.; Ng, C. Y. J. Chem. Phys. 2006, 124, 34309.

(31) Dahl, D. A.; Appelhans, A. D. SIMION 3D, Version 7.0; Scientific Instrument Services, Inc.: Ringoes, USA, 2004.

(32) Jee, Y. J.; Jung, Y. J.; Jung, K. H. J. Chem. Phys. 2006, 115, 9739.
(33) Callaghan, R.; Gordon, R. J. J. Chem. Phys. 1990, 93, 4624.

(34) Li, J.; Yang, J.; Mo, Y.; Lau, K. C.; Qian, X. M.; Song, Y.; Liu, J.; Ng, C. Y. J. Chem. Phys. 2007, 126, 184304.

(35) Arepalli, S.; Presser, N.; Robie, D.; Gordon, R. J. Chem. Phys. Lett. 1985, 117, 64.

(36) Frisch, M. J.; Trucks, G. W.; Schlegel, H. B.; et al . Gaussian 03, Revision A.01; Gaussian Inc.: Pittsburgh, PA, 2003.
(37) Whitney, E. S.; Haeber, T.; Schuder, M. D.; Blair, A. C.; Nesbitt, D. J. J. Chem. Phys. 2006, 125, 054303.

(38) Fridgen, T. D.; Zhang, X. K.; Parnis, J. M.; March, R. E. J. Phys. Chem. A 2000, 104, 3487.

(39) Shimanouchi, T. Tables of Molecular Vibrational Frequencies Consolidated; National Bureau of Standards: Gaithersburg, MD, 1972; Vol. I, pp 1-160.
