CeO2-Cu2O 2D/3D S型异质结界面促进有序电荷转移以实现高效光催化析氢

doi:10.3866/PKU.WHXB202302051

物理化学学报 >> 2023, Vol. 39 >> Issue (12): 2302051.doi: 10.3866/PKU.WHXB202302051

CeO₂-Cu₂O 2D/3D S型异质结界面促进有序电荷转移以实现高效光催化析氢

张利君¹^,², 吴有林¹, Tsubaki Noritatsu²^,*(), 靳治良¹^,*()

¹ 北方民族大学化学与化学工程学院，银川 750021
² 富山大学工学部，应用化学系，五福 3190，富山 930-8555，日本

收稿日期:2023-02-28 录用日期:2023-04-10 发布日期:2023-04-17
通讯作者: Tsubaki Noritatsu,靳治良 E-mail:tsubaki@eng.u-toyama.ac.jp;zl-jin@nun.edu.cn
基金资助:
国家自然科学基金(22062001);宁夏废弃食用油转化为清洁能源高附加值化学品创新团队和低品位资源高值化利用及环境化工一体化技术创新团队资助项目

2D/3D S-Scheme Heterojunction Interface of CeO₂-Cu₂O Promotes Ordered Charge Transfer for Efficient Photocatalytic Hydrogen Evolution

Lijun Zhang¹^,², Youlin Wu¹, Noritatsu Tsubaki²^,*(), Zhiliang Jin¹^,*()

¹ School of Chemistry and Chemical Engineering, North Minzu University, Yinchuan 750021, China
² Department of Applied Chemistry, Graduate School of Engineering, University of Toyama, Gofuku 3190, Toyama 930-8555, Japan

Received:2023-02-28 Accepted:2023-04-10 Published:2023-04-17
Contact: Noritatsu Tsubaki, Zhiliang Jin E-mail:tsubaki@eng.u-toyama.ac.jp;zl-jin@nun.edu.cn
Supported by:
the National Natural Science Foundation of China(22062001);the Innovative Team for Transforming Waste Cooking Oil into Clean Energy and High Value-Added Chemicals, Ningxia Low-Grade Resource High Value Utilization and Environmental Chemical Integration Technology Innovation Team Project

摘要/Abstract

摘要：

快速的本征载流子复合严重限制了CeO₂基催化材料的光催化活性。在这里，提出了一种异质结界面工程策略，合理地进行界面调节。构建了具有强电子相互作用的2D/3D S型异质结。合成了一种用于固定在2D CeO₂边缘的3D Cu₂O颗粒的复合光催化剂。密度泛函理论(DFT)第一性原理计算和实验结果表明，CeO₂和Cu₂O之间形成强耦合的S型异质结电子传输界面，实现了高效的载流子分离和传输。复合催化剂的光催化析氢活性在以三乙醇胺为牺牲剂的体系中得到大幅提高，是CeO₂的48倍。此外，CeO₂-Cu₂O光催化剂还具有高度稳定的光催化氢活性。这为在新型纳米复合结构中构建独特界面提供了一种通用策略。

关键词: CeO₂, Cu₂O, DFT, S型异质结, 光催化析氢

Abstract:

Rapid intrinsic carrier recombination severely restricts the photocatalytic activity of CeO₂-based catalytic materials. In this study, a heterogeneous interfacial engineering strategy is proposed to rationally perform interface modulation. A 2D/3D S-scheme heterojunction with strong electronic interactions was constructed. A composite photocatalyst was synthesized for the 3D Cu₂O particles anchored at the edge of 2D CeO₂. First-principles calculations (based on density functional theory) and the experimental results show that a strongly coupled S-scheme heterojunction electron transport interface is formed between CeO₂ and Cu₂O, resulting in efficient carrier separation and transfer. The photocatalytic hydrogen evolution activity of the composite catalyst is significantly improved in the system with triethanolamine as the sacrificial agent and is 48 times as that of CeO₂. In addition, the resulting CeO₂-Cu₂O photocatalyst affords highly stable photocatalytic hydrogen activity. This provides a general technique for constructing unique interfaces in novel nanocomposite structures.

Key words: CeO₂, Cu₂O, DFT, S-scheme heterostructure, Photocatalytic hydrogen evolution

张利君, 吴有林, Tsubaki Noritatsu, 靳治良. CeO₂-Cu₂O 2D/3D S型异质结界面促进有序电荷转移以实现高效光催化析氢[J]. 物理化学学报, 2023, 39(12), 2302051. doi: 10.3866/PKU.WHXB202302051

Lijun Zhang, Youlin Wu, Noritatsu Tsubaki, Zhiliang Jin. 2D/3D S-Scheme Heterojunction Interface of CeO₂-Cu₂O Promotes Ordered Charge Transfer for Efficient Photocatalytic Hydrogen Evolution[J]. Acta Phys. -Chim. Sin. 2023, 39(12), 2302051. doi: 10.3866/PKU.WHXB202302051

链接本文: https://www.whxb.pku.edu.cn/CN/10.3866/PKU.WHXB202302051

https://www.whxb.pku.edu.cn/CN/Y2023/V39/I12/2302051

图/表 9

Fig 1

Table 1

Fig 2

Fig 3

Fig 4

Fig 5

Fig 6

Fig 7

Fig 8

参考文献 68

1	Nishiyama H. S. ; Yamada T. ; Nakabayashi M. ; Maehara Y. ; Yamaguchi M. ; Kuromiya Y. ; Tokudome H. ; Akiyama S. ; Watanabe T. ; Narushima R. ; et al Nature 2021, 598, 304. doi: 10.1038/s41586-021-03907-3
2	Takata T. ; Jiang J. Z. ; Sakata Y. ; Nakabayashi M. ; Shibata N. ; Nandal V. ; Seki K. ; Hisatomi T. ; Domen K. Nature 2020, 581, 411. doi: 10.1038/s41586-020-2278-9
3	Zhang L. J. ; Jiang X. D. ; Jin Z. L. ; Tsubaki N. J. Mater. Chem. A 2022, 10, 10715. doi: 10.1039/D2TA00839D
4	Cheng C. ; He B. ; Fan J. J. ; Cheng B. ; Cao S. W. ; Yu J. G. Adv. Mater 2021, 33, 2100317. doi: 10.1002/adma.202100317
5	Xiao L. ; Zhang Q. ; Chen P. ; Chen L. ; Ding F. ; Tang J. ; Li Y. J. ; Au C. ; Yin S. F. Appl. Catal. B: Environ. 2019, 248, 380. doi: 10.1016/j.apcatb.2019.02.012
6	Li X. ; Yu J. G. ; Mietek J. ; Chen X. B. Chem. Rev. 2019, 119, 3962. doi: 10.1021/acs.chemrev.8b00400
7	Wang C. C. ; Yan R. Y. ; Cai M. J. ; Liu Y.P. ; Li S. J. Appl. Surf. Sci. 2023, 610, 155346. doi: 10.1016/j.apsusc.2022.155346
8	Yang J. ; Wu X. H. ; Mei Z. H. ; Zhou S. ; Su Y. R. ; Wang G. H. Adv. Sustain. Syst. 2022, 6, 2200056. doi: 10.1002/adsu.202200056
9	Zhang L. J. ; Wang G. R. ; Hao X. Q. ; Jin Z. L. ; Wang Y. B. Chem. Eng. J. 2020, 395, 125113. doi: 10.1016/j.cej.2020.125113
10	Zhu L. Y. ; Ye R. H. ; Tang P. S. ; Xia P. F. Aust. J. Chem. 2022, 75, 795. doi: 10.1071/CH22098
11	Li Y. X. ; He R. C. ; Han P. ; Hou B. P. ; Peng S. Q. ; Ouyang C. Appl. Catal. B: Environ. 2020, 279, 119379. doi: 10.1016/j.apcatb.2020.119379
12	Zhang L. J. ; Jin Z. L. ; Tsubaki N. Chem. Eng. J. 2022, 438, 135238. doi: 10.1016/j.cej.2022.135238
13	Sharma D. ; Satsangi V. R. ; Shrivastav R. ; Waghmare U. V. ; Dass S. Int. J. Hydrog. Energy 2016, 41, 18339. doi: 10.1016/j.ijhydene.2016.08.079
14	Wetchakun N. ; Chaiwichain S. ; Inceesungvorn B. ; Pingmuang K. ; Phanichphant S. ; Minett A. I. ; Chen J. ACS Appl. Mater. Interface 2012, 4, 3718. doi: 10.1021/am300812n
15	Pu Y. ; Luo Y. D. ; Wei X. Q. ; Sun J. F. ; Li L. L. ; Zou W. X. ; Dong L. Appl. Catal. B: Environ. 2019, 254, 580. doi: 10.1016/j.apcatb.2019.04.093
16	Khan M. M. ; Ansari S. A. ; Pradhan D. ; Han D. H. ; Lee J. ; Cho M. H. Ind. Eng. Chem. Res. 2014, 53, 9754. doi: 10.1021/ie500986n
17	Xie S. L. ; Wang Z. L. ; Cheng F. L. ; Zhang P. ; Mai W. J. ; Tong Y. X. Nano Energy 2017, 34, 313. doi: 10.1016/j.nanoen.2017.02.029
18	Pang J. J. ; Li W. T. ; Cao Z. H. ; Xu J. J. ; Li X. ; Zhang X. K. Appl. Surf. Sci. 2018, 439, 420. doi: 10.1016/j.apsusc.2018.01.055
19	Chae B. W. ; Amna T. ; Hassan M. S. ; Deyab S. ; Khil M. S. Adv. Powder Technol. 2017, 28, 230. doi: 10.1016/j.apt.2016.09.010
20	Cai M. G. ; Liu Y. P. ; Wang C. C. ; Lin W. ; Li S. J. Sep. Purif. Technol. 2023, 304, 122401. doi: 10.1016/j.seppur.2022.122401
21	Liu S. C. ; Wang K. ; Yang M. X. ; Jin Z. L. Acta Phys. -Chim. Sin. 2022, 38, 2109023.
	刘珊池; 王凯; 杨梦雪; 靳治良; 物理化学学报, 2022, 38, 2109023. doi: 10.3866/PKU.WHXB202109023
22	Shen C. H. ; Chen Y. ; Xu X. J. ; Li X. Y. ; Wen X. J. ; Liu Z. T. ; Xing R. ; Guo H. ; Fei Z. H. J. Hazard. Mater. 2021, 416, 126217. doi: 10.1016/j.jhazmat.2021.126217
23	Paracchino A. ; Laporte V. ; Sivula K. ; Grätzel M. ; Thimsen E. Nat. Mater. 2011, 10, 456. doi: 10.1038/nmat3017
24	Li S. J. ; Cai M. J. ; Wang C. C. ; Liu Y. P. Adv. Fiber. Mater. 2023, doi: 10.1007/s42765-022-00253-5
25	Jiang J. W. ; Lim Y. S. ; Park S. ; Kim S. H. ; Yoon S. G. ; Piao L. H. Nanoscale 2017, doi: 10.1039/C6NR09934C
26	Xu H. L. ; Wang W. Z. ; Zhu W. J. Phys. Chem. B 2006, 110, 13829. doi: 10.1021/jp061934y
27	Li Q. ; Xu P. ; Zhang B. ; Tsai H. H. ; Zheng S. J. ; Wu G. ; Wang H. L. J. Phys. Chem. C 2013, 117, 13872. doi: 10.1021/jp403655y
28	Ahmed A. ; Gajbhiye N. S. ; Joshi A. G. Mater. Chem. Phys. 2011, 129, 740. doi: 10.1016/j.matchemphys.2011.04.042
29	Gong H. M. ; Li Y. J. ; Li H. Y. ; Jin Z. L. Langmuir 2022, 38, 2117. doi: 10.1021/acs.langmuir.1c03198
30	Zhang L. J. ; Jin Z. L. Nanoscale 2021, 13, 1340. doi: 10.1039/D0NR07821B
31	Li S. J. ; Wang C. C. ; Liu Y. P. ; Liu Y. Z. ; Cai M. J. ; Zhao W. ; Duan X. G. Chem. Eng. J. 2023, 455, 140943. doi: 10.1016/j.cej.2022.140943
32	Wang X. P. ; Li T. ; Zhu P. Dalton Trans. 2022, 51, 2912. doi: 10.1039/D1DT03605J
33	Qi Y. ; Ye J. W. ; Zhang S. Q. ; Tian Q. Z. ; Xu N. ; Tian P. ; Ning G. L. J. Alloy. Compd. 2019, 782, 780. doi: 10.1016/j.jallcom.2018.12.111
34	French M. ; Schwartz R. ; Stolz H. ; Redmer R. J. Phys. Condes. Matter 2009, 21, 015502. doi: 10.1088/0953-8984/21/1/015502
35	Han G. W. ; Xu F. Y. ; Cheng B. ; Li Y. J. ; Yu J. G. ; Zhang L. Y. Acta Phys. -Chim. Sin. 2022, 38, 2112037.
	韩高伟; 徐飞燕; 程蓓; 李佑稷; 余家国; 张留洋; 物理化学学报, 2022, 38, 2112037. doi: 10.3866/PKU.WHXB202112037
36	Wang G. R. ; Quan Y. K. ; Yang K. C. ; Jin Z. L. J. Mater. Sci. Technol. 2022, 121, 28. doi: 10.1016/j.jmst.2021.11.073
37	Li S. J. ; Cai M. J. ; Liu Y. P. ; Wang C. C. ; Lv K. L. ; Chen X. B. Chin. J. Catal. 2022, 43, 2652. doi: 10.1016/S1872-2067(22)64106-8
38	Shi H. L. ; Pan H. ; Zhang Y. W. ; Yakobson B. I. Phys. Rev. B 2013, 87, 155304. doi: 10.1103/PhysRevB.87.155304
39	Hensel J. ; Wang G. M. ; Li Y. ; Zhang J. Z. Nano Lett. 2010, 10, 478. doi: 10.1021/nl903217w
40	Sayed M. ; Yu J. G. ; Liu G. ; Jaroniec M. Chem. Rev. 2022, 122, 10484. doi: 10.1021/acs.chemrev.1c00473
41	Jiang Y. F. ; Yuan C. Z. ; Xie X. ; Zhou X. ; Jiang N. ; Wang X. ; Imran M. ; Xu A.W. ACS Appl. Mater. Interface 2017, 9, 9756. doi: 10.1021/acsami.7b00293
42	Hu S. C. ; Zhou F. ; Wang L. Z. ; Zhang J. L. Catal. Commun. 2011, 12, 794. doi: 10.1016/j.catcom.2011.01.027
43	He C. ; Yu Y. K. ; Chen C. W. ; Yue L. ; Qiao N. ; Shen Q. ; Chen J. S. ; Hao Z. P. RSC Adv. 2013, 3, 19639. doi: 10.1039/C3RA42566E
44	Wang Y. P. ; Hao X. Q. ; Zhang L. J. ; Li Y. B. ; Jin Z. L. Energy Fuel 2020, 34, 2599. doi: 10.1021/acs.energyfuels.9b04386
45	Chen J. ; Shen S. H. ; Guo P. H. ; Wang M. ; Wu P. ; Wang X. X. ; Guo L. J. Appl. Catal. B: Environ. 2014, 152, 335. doi: 10.1016/j.apcatb.2014.01.047
46	Chen J. ; Shen S. H. ; Wua P. ; Guo L. J. Green Chem. 2015, 17, 509. doi: 10.1039/C4GC01683A
47	Liu H. ; Su P. ; Jin Z. L. ; Guo Q. J. Dalton Trans. 2020, 49, 13393. doi: 10.1039/D0DT02753G
48	Jin Z. L. ; Zhang L. J. Mater. Sci. Technol. 2020, 49, 144. doi: 10.1016/j.jmst.2020.02.025
49	Zhang L. J. ; Wu Y. L. ; Li J. K. ; Jin Z. L. ; Li Y. J. ; Tsubaki N. Mater. Today Phys. 2022, 27, 100767. doi: 10.1016/j.mtphys.2022.100767
50	Zhang L. J. ; Hao X. Q. ; Wang Y. P. ; Jina Z. L. ; Ma Q. X. Chem. Eng. J. 2020, 391, 123545. doi: 10.1016/j.cej.2019.123545
51	Wu X. H. ; Chen G. Q. ; Wang J. ; Li J. M. ; Wang G. H. Acta Phys. -Chim. Sin. 2023, 39, 2212016.
	吴新鹤; 陈郭强; 王娟; 李金懋; 王国宏; 物理化学学报, 2023, 39, 2212016. doi: 10.3866/PKU.WHXB202212016
52	Li J. K. ; Li M. ; Li Y. L. ; Guo X. ; Jin Z. L. Sep. Purif. Technol. 2022, 288, 120588. doi: 10.1016/j.seppur.2022.120588
53	Pan J. W. ; Zhang G. X. ; Guan Z. J. ; Zhao Q. Y. ; Li G. Q. ; Yang J. J. ; Li Q. Y. ; Zou. Z. G. J. Energy. Chem 2021, 58, 408. doi: 10.1016/j.jechem.2020.10.030
54	Zhang L. J. ; Jin Z. L. ; Tsubaki N. ACS Appl. Mater. Interface 2021, 13, 18507. doi: 10.1021/acsami.1c14987
55	Bie C. B. ; Yu H. G. ; Cheng B. ; Ho W. K. ; Fan J. J. ; Yu J. G. Adv. Mater. 2021, 33, 2003521. doi: 10.1002/adma.202003521
56	Yan T. ; Wang Y. P. ; Cao Y. ; Liu H. ; Jin Z. L. Appl. Catal. A: Gen. 2022, 630, 118457. doi: 10.1016/j.apcata.2021.118457
57	Zhang L. J. ; Jin Z. L. ; Tsubaki N. Nanoscale 2021, 13, 50996. doi: 10.1039/D1NR05452J
58	Dong Y. J. ; Hu Q. Y. ; Li B. A. ; Li X. H. ; Chen M. X. ; Zhang M. Y. ; Feng F. ; Ding Y. Appl. Catal. B: Environ. 2022, 304, 120998. doi: 10.1016/j.apcatb.2021.120998
59	Yan X. ; Jin Z. L. Chem. Eng. J. 2021, 420, 127682. doi: 10.1016/j.cej.2020.127682
60	Liu Y. ; Hu H. Q. ; Jin Z. L. Acta Phys. -Chim. Sin. 2021, 37, 2008030.
	刘阳; 胡海强; 靳治良; 物理化学学报, 2021, 37, 2008030. doi: 10.3866/PKU.WHXB202008030
61	Wu Y. L. ; Li Y. J. ; Zhang L. J. ; Jin Z. L. ChemCatChem 2022, 14, e202101656. doi: 10.1002/cctc.202101656
62	Hezam A. ; Namratha K. ; Drmosh Q. A. ; Ponnamma D. ; Wang J. W. ; Prasad S. ; Momin Ahamed M. ; Cheng C. ; Byrappa K. ACS Appl. Nano Mater. 2020, 3, 138. doi: 10.1021/acsanm.9b01833
63	Xia P. F. ; Cao S. W. ; Zhu B. C. ; Liu M. J. ; Shi M. S. ; Yu J. G. ; Zhang Y. F. Angew. Chem. Int. Edit. 2020, 59, 5218. doi: 10.1002/anie.201916012
64	Guo F. ; Shi W. L. ; Wang H. B. ; Han M. M. ; Li H. ; Huang H. ; Liu Y. ; Kang Z. H. Catal. Sci. Technol. 2017, 7, 3325. doi: 10.1039/C7CY00960G
65	Liang Z. Z. ; Shen P. C. ; Zhang P. ; Li Y. J. ; Li N. ; Li X. Chin. J. Catal. 2022, 43, 2581. doi: 10.1016/S1872-2067(22)64130-5
66	Jiang Z. C. ; Zhang L. Y. ; Yu J. G. J. Chin. Ceramic Soc. 2023, 51, 73. doi: 10.14062/j.issn.0454-5648.20220459
67	Zhang L. Y. ; Zhang J. J. ; Yu H. G. ; Yu J. G. Adv. Mater. 2022, 34, 2107668. doi: 10.1002/adma.202107668
68	Wu X. H. ; Ma H. Q. ; Wang K. ; Wang J. ; Wang G. H. ; Yu H. G. J. Colloid Interface Sci. 2023, 633, 817. doi: 10.1016/j.jcis.2022.11.143

Samples	m(CeO₂)/g	V/mL		Atomic fraction
Samples	m(CeO₂)/g	0.1 mol∙L⁻¹ Cu(AC)₂∙H₂O	0.6 mol∙L⁻¹ NaOH	Ce	O	Cu
CCO-1	0.35	5	5	17.54%	74.54%	7.92%
CCO-2	0.35	10	10	18.80%	71.81%	9.39%
CCO-3	0.35	15	15	18.57%	70.74%	10.69%
CCO-4	0.35	20	20	17.87%	67.61%	14.53%
