微波辅助合成促进铬酸铋晶体的光生电荷分离

doi:10.3866/PKU.WHXB202303034

物理化学学报 >> 2024, Vol. 40 >> Issue (1): 2303034.doi: 10.3866/PKU.WHXB202303034

所属专题：多物理场能源催化转化

微波辅助合成促进铬酸铋晶体的光生电荷分离

张珹博¹^,², 陶晓萍¹^,², 蒋文超¹^,³, 郭俊雪¹^,³, 张鹏飞¹^,², 李灿¹^,²^,³, 李仁贵¹^,²^,*()

¹ 中国科学院大连化学物理研究所, 催化基础国家重点实验室, 大连洁净能源国家实验室, 能源材料化学协同创新中心, 辽宁大连 116023
² 中国科学院大学, 北京 100049
³ 中国科学技术大学化学与材料科学学院, 合肥 230026

收稿日期:2023-03-16 录用日期:2023-04-14 发布日期:2023-08-21
通讯作者: 李仁贵 E-mail:rgli@dicp.ac.cn
基金资助:
国家重点研发计划(2021YFA1502300);国家自然科学基金“人工光合成”基础科学中心(FReCAP)(22088102);国家自然科学基金(22090033);国家自然科学基金(22272165)

Microwave-Assisted Synthesis of Bismuth Chromate Crystals for Photogenerated Charge Separation

Chengbo Zhang¹^,², Xiaoping Tao¹^,², Wenchao Jiang¹^,³, Junxue Guo¹^,³, Pengfei Zhang¹^,², Can Li¹^,²^,³, Rengui Li¹^,²^,*()

¹ State Key Laboratory of Catalysis, Dalian National Laboratory for Clean Energy, Dalian Institute of Chemical Physics, Chinese Academy of Sciences, iChEM (Collaborative Innovation Center of Chemistry for Energy Materials), Dalian 116023, Liaoning Province, China
² University of Chinese Academy of Sciences, Beijing 100049, China
³ School of Chemistry and Materials Science, University of Science and Technology of China, Hefei 230026, China

Received:2023-03-16 Accepted:2023-04-14 Published:2023-08-21
Contact: Rengui Li E-mail:rgli@dicp.ac.cn
Supported by:
the National Key Research and Development Program of China(2021YFA1502300);Fundamental Research Center of Artificial Photosynthesis (FReCAP) under National Natural Science Foundation of China(22088102);R.L. thanks the support from National Natural Science Foundation of China(22090033);R.L. thanks the support from National Natural Science Foundation of China(22272165)

1. WHXB202303034-SI-4p.pdf(1448KB)

摘要/Abstract

摘要：

为了将可再生太阳能转化为化学物质，探索具有宽光谱响应的光催化剂用于光催化分解水越来越受到人们的关注。作为铋基层状金属氧化物的一员，铬酸铋(Bi₂CrO₆)的带隙约为1.9 eV，在利用大范围太阳光谱方面具有潜力。然而，Bi₂CrO₆较差的电荷分离性能限制了其在光催化中的应用。本文采用微波辅助水热合成方法制备了具有规则形貌的Bi₂CrO₆晶体，该晶体具有结晶度高、形貌均匀的优点。与传统制备方法相比，微波辐照实现了体系的快速加热，极大地加速了成核和生长的化学反应，从而在几分钟内形成了Bi₂CrO₆晶体。微波辅助合成的Bi₂CrO₆晶体在光催化和光电化学测试中表现出更好的光生电荷分离以及水氧化活性。此外实验中观察到光生电子和空穴在Bi₂CrO₆晶体的不同晶面之间发生空间分离，通过进一步在不同晶面上光沉积选择性负载还原和氧化助催化剂，显著增强了光催化活性。这项工作为制备高效太阳能转换的半导体光催化剂提供了一种可行的解决方案。

关键词: 微波合成, 铬酸铋, 半导体, 光催化, 水氧化

Abstract:

The conversion of renewable solar energy into chemical energy is an important topic in research. Recently, bismuth chromate (Bi₂CrO₆) has attracted attention in photocatalytic research, particularly for its potential applications in pollutant degradation and water splitting. This layered metal oxide exhibits a narrow optical band gap of approximately 1.9 eV and can utilize most of visible light in the solar spectrum. However, the photocatalytic activity of Bi₂CrO₆ is relatively low, and its poor charge separation properties restrict its practical applications. Herein, we report a microwave-assisted hydrothermal method for the fabrication of Bi₂CrO₆ crystals with high crystallinity and uniform morphology. Compared with the conventional preparations, microwave irradiation induces rapid volumetric heating and greatly accelerates nucleation and growth reactions, forming Bi₂CrO₆ crystals within minutes. Multiple characterization methods, including X-ray diffraction, Raman scattering, and scanning electron microscopy, were employed to examine the crystallinity and morphologies of the samples. Microwave-assisted synthesized Bi₂CrO₆ crystals showed better water oxidation activity in photocatalytic and photoelectrochemical tests than the conventional samples. Oxygen evolution rates were boosted 7.2 and 3.1 times using AgNO₃ and Fe(NO₃)₃ as electron acceptors, respectively. Further investigations showed that microwave-assisted Bi₂CrO₆ crystals exhibited improved photogenerated charge separation. The average lifetime of photogenerated carriers, calculated from time-resolved photoluminescence results, also showed an increase. Furthermore, using photodeposition of metals and oxides as probes, the spatial separation of photogenerated electrons and holes was demonstrated to take place between {001} top and side facets of the Bi₂CrO₆ crystal samples. Loading reduction and oxidation cocatalysts onto different facets significantly enhanced the photocatalytic activities. These results enforce the promise of microwave-assisted Bi₂CrO₆ crystal synthesis for photocatalytic water-splitting applications and present a solution for efficient solar-energy conversion.

Key words: Microwave synthesis, Bismuth chromate, Semiconductor, Photocatalysis, Water oxidation

张珹博, 陶晓萍, 蒋文超, 郭俊雪, 张鹏飞, 李灿, 李仁贵. 微波辅助合成促进铬酸铋晶体的光生电荷分离[J]. 物理化学学报, 2024, 40(1), 2303034. doi: 10.3866/PKU.WHXB202303034

Chengbo Zhang, Xiaoping Tao, Wenchao Jiang, Junxue Guo, Pengfei Zhang, Can Li, Rengui Li. Microwave-Assisted Synthesis of Bismuth Chromate Crystals for Photogenerated Charge Separation[J]. Acta Phys. -Chim. Sin. 2024, 40(1), 2303034. doi: 10.3866/PKU.WHXB202303034

链接本文: https://www.whxb.pku.edu.cn/CN/10.3866/PKU.WHXB202303034

https://www.whxb.pku.edu.cn/CN/Y2024/V40/I1/2303034

图/表 8

Fig 1

Fig 2

Fig 3

Fig 4

Fig 5

Fig 6

Fig 7

Fig 8

参考文献 40

1	Inoue Y. Energy Environ. Sci. 2009, 2, 364. doi: 10.1039/B816677N
2	Maeda K. ; Domen K. J. Phys. Chem. C 2007, 111, 7851. doi: 10.1021/jp070911w
3	He R. ; Cao S. ; Yu J. Acta Phys. -Chim. Sin. 2016, 32, 2841.
	赫荣安; 曹少文; 余家国; 物理化学学报, 2016, 32, 2841. doi: 10.3866/PKU.WHXB201611021
4	He R. ; Chen R. ; Luo J. ; Zhang S. ; Xu D. Acta Phys. -Chim. Sin. 2021, 37, 2011022.
	赫荣安; 陈容; 罗金花; 张世英; 许第发; 物理化学学报, 2021, 37, 2011022. doi: 10.3866/PKU.WHXB202011022
5	Tao X. ; Zhao Y. ; Mu L. ; Wang S. ; Li R. ; Li C. Adv. Energy Mater. 2018, 8, 1701392. doi: 10.1002/aenm.201701392
6	He R. ; Xu D. ; Cheng B. ; Yu J. ; Ho W. Nanoscale Horiz. 2018, 3, 464. doi: 10.1039/c8nh00062j
7	Xu M. ; Yang J. ; Sun C. ; Liu L. ; Cui Y. ; Liang B. Chem. Eng. J. 2020, 389, 124402. doi: 10.1016/j.cej.2020.124402
8	Hasanvandian F. ; Moradi M. ; Samani S. A. ; Kakavandi B. ; Setayesh S. R. ; Noorisepehr M. Chemosphere 2022, 287, 132273. doi: 10.1016/j.chemosphere.2021.132273
9	Li Z. ; Zhang Z. ; Wang L. ; Meng X. J. Catal. 2020, 382, 40. doi: 10.1016/j.jcat.2019.12.001
10	Lai K. ; Wei W. ; Dai Y. ; Zhang R. ; Huang B. Rare Metals 2011, 30, 166. doi: 10.1007/s12598-011-0262-0
11	Liu Y. H. ; Li J. B. ; Liang J. K. ; Luo J. ; Ji L. N. ; Zhang J. Y. ; Rao G. H. Mater. Chem. Phys. 2008, 112, 239. doi: 10.1016/j.matchemphys.2008.05.038
12	Zhang Q. ; Huang B. ; Wang P. ; Zhang X. ; Qin X. ; Wang Z. Int. J. Photoenergy 2012, 2012, 461291. doi: 10.1155/2012/461291
13	Chawla H. ; Chandra A. ; Ingole P. P. ; Garg S. J. Ind. Eng. Chem. 2021, 95, 1. doi: 10.1016/j.jiec.2020.12.028
14	Tao X. ; Zhou H. ; Zhang C. ; Ta N. ; Li R. ; Li C. Adv. Mater. 2023, 35, 2211182. doi: 10.1002/adma.202211182
15	Jiang W. ; Ni C. ; Zhang L. ; Shi M. ; Qu J. ; Zhou H. ; Zhang C. ; Chen R. ; Wang X. ; Li C. ; et al Angew. Chem. Int. Ed. 2022, 61, e202207161. doi: 10.1002/anie.202207161
16	Mu L. ; Zhao Y. ; Li A. ; Wang S. ; Wang Z. ; Yang J. ; Wang Y. ; Liu T. ; Chen R. ; Zhu J. ; et al Energy Environ. Sci. 2016, 9, 2463. doi: 10.1039/C6EE00526H
17	Shi M. ; Li G. ; Li J. ; Jin X. ; Tao X. ; Zeng B. ; Pidko E. A. ; Li R. ; Li C. Angew. Chem. Int. Ed. 2020, 59, 6590. doi: 10.1002/anie.201916510
18	Zhao Y. ; Ding C. ; Zhu J. ; Qin W. ; Tao X. ; Fan F. ; Li R. ; Li C. Angew. Chem. Int. Ed. 2020, 59, 9653. doi: 10.1002/anie.202001438
19	Zhao Y. ; Li R. ; Mu L. ; Li C. Cryst. Growth Des. 2017, 17, 2923. doi: 10.1021/acs.cgd.7b00291
20	Rodrigues B. S. ; Branco C. M. ; Corio P. ; Souza J. S. Cryst. Growth Des. 2020, 20, 3673. doi: 10.1021/acs.cgd.9b01517
21	Xie J. ; Shevlin S. A. ; Ruan Q. ; Moniz S. J. A. ; Liu Y. ; Liu X. ; Li Y. ; Lau C. C. ; Guo Z. X. ; Tang J. Energy Environ. Sci. 2018, 11, 1617. doi: 10.1039/C7EE02981K
22	Mei Z. H. ; Wang G. H. ; Yan S. D. ; Wang J. Acta Phys. -Chim. Sin. 2021, 37, 2009097.
	梅子慧; 王国宏; 严素定; 王娟; 物理化学学报, 2021, 37, 2009097. doi: 10.3866/pku.Whxb202009097
23	Huang C. ; Wen Y. ; Ma J. ; Dong D. ; Shen Y. ; Liu S. ; Ma H. ; Zhang Y. Nat. Commun. 2021, 12, 320. doi: 10.1038/s41467-020-20521-5
24	Wu L. ; Bi J. ; Li Z. ; Wang X. ; Fu X. Catal. Today 2008, 131, 15. doi: 10.1016/j.cattod.2007.10.089
25	Wang J. ; Wu W. ; Kondo H. ; Fan T. ; Zhou H. Nanotechnology 2022, 33, 342002. doi: 10.1088/1361-6528/ac6c97
26	Yang G. ; Park S.-J. Materials 2019, 12, 1177. doi: 10.3390/ma12071177
27	Anumol E. A. ; Kundu P. ; Deshpande P. A. ; Madras G. ; Ravishankar N. ACS Nano 2011, 5, 8049. doi: 10.1021/nn202639f
28	Chen Y. ; Yang W. ; Gao S. ; Zhu L. ; Sun C. ; Li Q. ChemSusChem 2018, 11, 1521. doi: 10.1002/cssc.201800180
29	Yang Z. ; Shen M. ; Dai K. ; Zhang X. ; Chen H. Appl. Surf. Sci. 2018, 430, 505. doi: 10.1016/j.apsusc.2017.08.072
30	Hamza M. A. ; El-Shazly A. N. ; Allam N. K. Mater. Lett. 2020, 262, 127188. doi: 10.1016/j.matlet.2019.127188
31	Bandiello E. ; Errandonea D. ; Martinez-Garcia D. ; Santamaria-Perez D. ; Manjón F. J. Phys. Rev. B 2012, 85, 024108. doi: 10.1103/PhysRevB.85.024108
32	Frost R. L. J. Raman Spectrosc. 2004, 35, 153. doi: 10.1002/jrs.1121
33	Leandro M. K. D. N. S. ; Moura J. V. B. ; Freire P. D. T. C. ; Vega M. L. ; Lima C. D. L. ; Hidalgo Á. A. ; Araújo A. C. J. D. ; Freitas P. R. ; Paulo C. L. R. ; Sousa A. K. D. ; et al Antibiotics 2021, 10, 1068. doi: 10.3390/antibiotics10091068
34	Chaves M. D. S. ; Lima G. D. ; De Assis M. ; Mendonca C. D. S. ; Pinatti I. M. ; Gouveia A. F. ; Rosa I. L. V. ; Longo E. ; Almeida M. A. P. ; Franco T. J. Solid State Chem. 2019, 274, 270. doi: 10.1016/j.jssc.2019.03.031
35	Lu J. ; Zhou W. ; Zhang X. ; Xiang G. J. Phys. Chem. Lett. 2020, 11, 1038. doi: 10.1021/acs.jpclett.9b03575
36	Chen X. ; Xu Y. ; Ma X. ; Zhu Y. Natl. Sci. Rev. 2020, 7, 652. doi: 10.1093/nsr/nwz198
37	Meng X. ; Zhang Z. J. Photochem. Photobiol. A 2015, 310, 33. doi: 10.1016/j.jphotochem.2015.04.024
38	Gao X. ; Huang K. ; Zhang Z. ; Meng X. Chem. Commun. 2022, 58, 2014. doi: 10.1039/D1CC06734F
39	Li R. ; Zhang F. ; Wang D. ; Yang J. ; Li M. ; Zhu J. ; Zhou X. ; Han H. ; Li C. Nat. Commun. 2013, 4, 1432. doi: 10.1038/ncomms2401
40	Li R. ; Tao X. ; Chen R. ; Fan F. ; Li C. Chem. Eur. J. 2015, 21, 14337. doi: 10.1002/chem.20150256
