基于金属-氮-碳结构催化剂的质子交换膜燃料电池研究进展

doi:10.3866/PKU.WHXB202010048

Abstract

Abstract:

Proton-exchange membrane fuel cells (PEMFCs) directly transform chemical energy into electrical energy with high energy density and zero carbon emissions, thereby offering a clean energy alternative for fossil fuels and vehicle electrification. However, the existing PEMFCs rely on Pt-based catalysts, especially at the cathode side wherein the sluggish oxygen reduction reaction (ORR) takes place, resulting in high cost and limiting their commercial applications. Therefore, there is a strong interest in developing platinum group metal-free (PGM-free) PEMFCs. Although impressive advancements have been made since metal-nitrogen-carbon (M-N-C) catalysts have been developed as promising candidates for low-cost cathode catalysts, PGM-free PEMFCs still suffer from insufficient activity and durability. Owing to the intricate structure of the tri-phase interface and mass transport limitation, the M-N-C catalysts with high ORR activity in rotating disk electrode (RDE) tests still suffer from unexpected problems such as showing low activity and undesired rapid degradation process in real fuel cell conditions. Therefore, a comprehensive understanding of the active sites and influences of the M-N-C catalyst structure and cathode structure on the PEMFC performance will promote the development of PGM-free PEMFCs. Herein, with an aim to increase the activity and durability of PEMFCs based on M-N-C catalysts, we summarize the recent progress in understanding the active sites of M-N-C catalysts and the relationships between the structures of catalysts/catalyst layers and device performances. At the catalyst level, multiple delicately designed synthetic strategies suggest that attractive device performances can be obtained by tailoring the intrinsic activity and density of the catalyst active sites while engineering the porosity of catalysts to improve the utilization of active sites. Additionally, integrating the catalyst ink into the cathode catalyst layers in PGM-free PEMFC is pivotal for transforming the impressive ORR performance of catalysts in the RDE test to fuel cell performance. Accordingly, the recent advances in the enhancement of mass transfer and charge transport to achieve remarkable fuel cell performance were also included by rationally designing ionomer contents, catalyst morphology, and fabrication process of cathodic catalyst layers. Moreover, durability is the Achilles heel of PEMFCs with M-N-C catalysts, which is currently far behind the commercial requirements. The possible degradation mechanisms and the recent progress in seeking the corresponding solutions are also discussed in this review, including the decomposition of metal species, protonation of nitrogen sites, corrosion of carbon support, and micropore flooding. Based on these insights, the perspective is proposed by articulating open challenges and opportunities in materials innovations and device engineering with an aim to achieve practical M-N-C based PEMFCs.

Key words: Proton-exchange membrane fuel cell, Platinum group metal-free catalyst, Metal-nitrogen-carbon, Oxygen reduction reaction, Electrolysis

Liang Ding, Tang Tang, Jin-Song Hu. Recent Progress in Proton-Exchange Membrane Fuel Cells Based on Metal-Nitrogen-Carbon Catalysts[J]. Acta Phys. -Chim. Sin. 2021, 37(9), 2010048. doi: 10.3866/PKU.WHXB202010048

Figures/Tables 20

References 109

1	Debe M. K. Nature 2012, 486, 43. doi: 10.1038/nature11115
2	Wang Y. ; Chen K. S. ; Mishler J. ; Cho S. C. ; Adroher X. C. Appl. Energy 2011, 88, 981. doi: 10.1016/j.apenergy.2010.09.030
3	Chen Z. W. ; Higgins D. ; Yu A. P. ; Zhang L. ; Zhang J. J. Energy Environ. Sci. 2011, 4, 3167. doi: 10.1039/C0EE00558D
4	Peighambardoust S. J. ; Rowshanzamir S. ; Amjadi M. Int. J. Hydrogen Energy 2010, 35, 9349. doi: 10.1016/j.ijhydene.2010.05.017
5	Pachauri R. K. ; Chauhan Y. K. Renew. Sustain. Energy Rev. 2015, 43, 1301. doi: 10.1016/j.rser.2014.11.098
6	Garland N. L. ; Papageorgopoulos D. C. ; Stanford J. M. Energy Procedia 2012, 28, 2. doi: 10.1016/j.egypro.2012.08.034
7	Mustain W. E. ; Chatenet M. ; Page M. ; Kim Y. S. Energy Environ. Sci. 2020, 13, 2805. doi: 10.1039/D0EE01133A
8	Winter M. ; Brodd R. J. Chem. Rev. 2004, 104, 4245. doi: 10.1021/cr020730k
9	Cano Z. P. ; Banham D. ; Ye S. Y. ; Hintennach A. ; Lu J. ; Fowler M. ; Chen Z. Nat. Energy 2018, 3, 279. doi: 10.1038/s41560-018-0108-1
10	Staffell I. ; Scamman D. ; Velazquez-Abad A. ; Balcombe P. ; Dodds P. E. ; Ekins P. ; Shah N. ; Ward K. R. Energy Environ. Sci. 2019, 12, 463. doi: 10.1039/C8EE01157E
11	Shin D. W. ; Guiver M. D. ; Lee Y. M. Chem. Rev. 2017, 117, 4759. doi: 10.1021/acs.chemrev.6b00586
12	Zhang M. ; Li J. J. ; Pan M. ; Xu D. S. Acta Phys. -Chim. Sin. 2011, 27, 1685.
	张敏; 李经建; 潘牧; 徐东升; 物理化学学报, 2011, 27, 1685. doi: 10.3866/PKU.WHXB20110726
13	Tang X. L. ; Zhang S. H. ; Yu J. ; Lü C. X. ; Chi Y. Q. ; Sun J. W. ; Song Y. ; Yuan D. ; Ma Z. L. ; Zhang L. X. Acta Phys. -Chim. Sin. 2020, 36, 1906070.
	唐小龙; 张盛辉; 于婧; 吕春晓; 迟雨晴; 孙君伟; 宋誉; 袁丁; 马兆立; 张立学; 物理化学学报, 2020, 36, 1906070. doi: 10.3866/PKU.WHXB201906070
14	Jaouen F. ; Jones D. ; Coutard N. ; Artero V. ; Strasser P. ; Kucernak A. Johnson Matthey Technol. Rev. 2018, 62, 231. doi: 10.1595/205651318X696828
15	Wang J. ; Ding W. ; Wei Z. D. Acta Phys. -Chim. Sin. 2021, 37, 2009094.
	王健; 丁炜; 魏子栋; 物理化学学报, 2021, 37, 2009094. doi: 10.3866/PKU.WHXB202009094
16	Tang T. ; Jiang W. J. ; Liu X. Z. ; Deng J. ; Niu S. ; Wang B. ; Jin S. F. ; Zhang Q. ; Gu L. ; Hu J. S. ; et al J. Am. Chem. Soc. 2020, 142, 7116. doi: 10.1021/jacs.0c01349
17	Tang T. ; Ding L. ; Jiang Z. ; Hu J. S. ; Wan L. J. Sci. China Chem. 2020, 63, 665. doi: 10.1007/s11426-020-9835-8
18	Jiang W. J. ; Hu W. L. ; Zhang Q. H. ; Zhao T. T. ; Luo H. ; Zhang X. ; Gu L. ; Hu J. S. ; Wan L. J. Chem. Commun. 2018, 54, 1307. doi: 10.1039/C7CC08149A
19	Zhang Y. ; Jiang W. J. ; Guo L. ; Zhang X. ; Hu J. S. ; Wei Z. ; Wan L. J. ACS Appl. Mat. Interfaces 2015, 7, 11508. doi: 10.1021/acsami.5b02467
20	Xu X. L. ; Xia Z. X. ; Zhang X. M. ; Sun R. L. ; Sun X. J. ; Li H. Q. ; Wu C. C. ; Wang J. H. ; Wang S. L. ; Sun G. Q. Appl. Catal. B 2019, 259, 118042. doi: 10.1016/j.apcatb.2019.118042
21	Banham D. ; Ye S. Y. ACS Energy Lett. 2017, 2, 629. doi: 10.1021/acsenergylett.6b00644
22	Reshetenko T. ; Serov A. ; Artyushkova K. ; Matanovic I. ; Sarah S. ; Atanassov P. J. Power Sources 2016, 324, 556. doi: 10.1016/j.jpowsour.2016.05.090
23	Feng Y. J. ; Gago A. ; Timperman L. ; Alonso-Vante N. Electrochim. Acta 2011, 56, 1009. doi: 10.1016/j.electacta.2010.09.085
24	Jasinski R. Nature 1964, 201, 1212. doi: 10.1038/2011212a0
25	Proietti E. ; Jaouen F. ; Lefèvre M. ; Larouche N. ; Tian J. ; Herranz J. ; Dodelet J. P. Nat. Commun. 2011, 2, 416. doi: 10.1038/ncomms1427
26	Li J. Z. ; Chen M. J. ; Cullen D. A. ; Hwang S. ; Wang M. ; Li B. Y. ; Liu K. X. ; Karakalos S. ; Lucero M. ; Zhang H. G. ; et al Nat. Catal. 2018, 1, 935. doi: 10.1038/s41929-018-0164-8
27	He Y. H. ; Hwang S. ; Cullen D. A. ; Uddin M. A. ; Langhorst L. ; Li B. Y. ; Karakalos S. ; Kropf A. J. ; Wegener E. C. ; Sokolowski J. ; et al Energy Environ. Sci. 2019, 12, 250. doi: 10.1039/C8EE02694G
28	Fu X. G. ; Li N. ; Ren B. H. ; Jiang G. P. ; Liu Y. R. ; Hassan F. M. ; Su D. ; Zhu J. B. ; Yang L. ; Bai Z. Y. ; et al Adv. Energy Mater. 2019, 9, 1803737. doi: 10.1002/aenm.201803737
29	Chung H. T. ; Cullen D. A. ; Higgins D. ; Sneed B. T. ; Holby E. F. ; More K. L. ; Zelenay P. Science 2017, 357, 479. doi: 10.1126/science.aan2255
30	Yang L. ; Cheng D. J. ; Xu H. X. ; Zeng X. F. ; Wan X. ; Shui J. J. ; Xiang Z. H. ; Cao D. P. Proc. Natl. Acad. Sci. U. S. A. 2018, 115, 6626. doi: 10.1073/pnas.1800771115
31	Wang Y. C. ; Lai Y. J. ; Song L. ; Zhou Z. Y. ; Liu J. G. ; Wang Q. ; Yang X. D. ; Chen C. ; Shi W. ; Zheng Y. P. ; et al Angew. Chem. Int. Ed. 2015, 54, 9907. doi: 10.1002/anie.201503159
32	Zhang C. ; Wang Y. C. ; An B. ; Huang R. Y. ; Wang C. ; Zhou Z. Y. ; Lin W. B. Adv. Mater. 2017, 29, 1604556. doi: 10.1002/adma.201604556
33	Wang X. X. ; Cullen D. A. ; Pan Y. ; Hwang S. ; Wang M. Y. ; Feng Z. X. ; Wang J. Y. ; Engelhard M. H. ; Zhang H. G. ; He Y. H. ; et al Adv. Mater. 2018, 30, 1706758. doi: 10.1002/adma.201706758
34	Tian J. ; Morozan A. ; Sougrati M. T. ; Lefèvre M. ; Chenitz R. ; Dodelet J. P. ; Jones D. ; Jaouen F. Angew. Chem. Int. Ed. 2013, 52, 6867. doi: 10.1002/anie.201303025
35	Wu G. ; More K. L. ; Johnston C. M. ; Zelenay P. Science 2011, 332, 443. doi: 10.1126/science.1200832
36	Yuan S. W. ; Shui J. L. ; Grabstanowicz L. ; Chen C. ; Commet S. ; Reprogle B. ; Xu T. ; Yu L. P. ; Liu D. J. Angew. Chem. Int. Ed. 2013, 52, 8349. doi: 10.1002/anie.201302924
37	Sa Y. J. ; Seo D. J. ; Woo J. ; Lim J. T. ; Cheon J. Y. ; Yang S. Y. ; Lee J. M. ; Kang D. ; Shin T. J. ; Shin H. S. ; et al J. Am. Chem. Soc. 2016, 138, 15046. doi: 10.1021/jacs.6b09470
38	Deng Y. J. ; Chi B. ; Li J. ; Wang G. H. ; Zheng L. ; Shi X. D. ; Cui Z. M. ; Du L. ; Liao S. J. ; Zang K. T. ; et al Adv. Energy Mater. 2019, 9, 1802856. doi: 10.1002/aenm.201802856
39	Wan X. ; Liu X. F. ; Li Y. C. ; Yu R. H. ; Zheng L. R. ; Yan W. S. ; Wang H. ; Xu M. ; Shui J. L. Nat. Catal. 2019, 2, 259. doi: 10.1038/s41929-019-0237-3
40	Shui J. L. ; Chen C. ; Grabstanowicz L. ; Zhao D. ; Liu D. J. Proc. Natl. Acad. Sci. U. S. A. 2015, 112, 10629. doi: 10.1073/pnas.1507159112
41	Wang J. ; Huang Z. Q. ; Liu W. ; Chang C. R. ; Tang H. L. ; Li Z. J. ; Chen W. X. ; Jia C. J. ; Yao T. ; Wei S. Q. ; et al J. Am. Chem. Soc. 2017, 139, 17281. doi: 10.1021/jacs.7b10385
42	Deng Y. J. ; Chi B. ; Tian X. L. ; Cui Z. M. ; Liu E. ; Jia Q. Y. ; Fan W. J. ; Wang G. H. ; Dang D. ; Li M. S. ; et al J. Mater. Chem. A 2019, 7, 5020. doi: 10.1039/C8TA11785C
43	Strickland K. ; Miner E. ; Jia Q. Y. ; Tylus U. ; Ramaswamy N. ; Liang W. T. ; Sougrati M. T. ; Jaouen F. ; Mukerjee S. Nat. Commun. 2015, 6, 7343. doi: 10.1038/ncomms8343
44	Fu X. G. ; Zamani P. ; Choi J. Y. ; Hassan F. M. ; Jiang G. P. ; Higgins D. C. ; Zhang Y. N. ; Hoque M. A. ; Chen Z. W. Adv. Mater. 2017, 29, 1604456. doi: 10.1002/adma.201604456
45	Zamani P. ; Higgins D. C. ; Hassan F. M. ; Fu X. G. ; Choi J. Y. ; Hoque M. A. ; Jiang G. P. ; Chen Z. W. Nano Energy 2016, 26, 267. doi: 10.1016/j.nanoen.2016.05.035
46	Mamtani K. ; Jain D. ; Zemlyanov D. ; Celik G. ; Luthman J. ; Renkes G. ; Co A. C. ; Ozkan U. S. ACS Catal. 2016, 6, 7249. doi: 10.1021/acscatal.6b01786
47	Jiang W. J. ; Gu L. ; Li L. ; Zhang Y. ; Zhang X. ; Zhang L. J. ; Wang J. Q. ; Hu J. S. ; Wei Z. D. ; Wan L. J. J. Am. Chem. Soc. 2016, 138, 3570. doi: 10.1021/jacs.6b00757
48	Litster S. ; McLean G. J. Power Sources 2004, 130, 61. doi: 10.1016/j.jpowsour.2003.12.055
49	Owejan J. P. ; Owejan J. E. ; Gu W. B. J. Electrochem. Soc. 2013, 160, F824. doi: 10.1149/2.072308jes
50	Stariha S. ; Artyushkova K. ; Workman M. J. ; Serov A. ; McKinney S. ; Halevi B. ; Atanassov P. J. Power Sources 2016, 326, 43. doi: 10.1016/j.jpowsour.2016.06.098
51	Banham D. ; Ye S. Y. ; Pei K. ; Ozaki J. i. ; Kishimoto T. ; Imashiro Y. J. Power Sources 2015, 285, 334. doi: 10.1016/j.jpowsour.2015.03.047
52	Shao Y. Y. ; Dodelet J. P. ; Wu G. ; Zelenay P. Adv. Mater. 2019, 31, 1807615. doi: 10.1002/adma.201807615
53	Thompson S. T. ; Papageorgopoulos D. Nat. Catal. 2019, 2, 558. doi: 10.1038/s41929-019-0291-x
54	Gasteiger H. A. ; Marković N. M. Science 2009, 324, 48. doi: 10.1126/science.1172083
55	Martinez U. ; Komini Babu S. ; Holby E. F. ; Chung H. T. ; Yin X. ; Zelenay P. Adv. Mater. 2019, 31, 1806545. doi: 10.1002/adma.201806545
56	Li J. K. ; Ghoshal S. ; Liang W. T. ; Sougrati M. T. ; Jaouen F. ; Halevi B. ; McKinney S. ; McCool G. ; Ma C. R. ; Yuan X. X. ; et al Energy Environ. Sci. 2016, 9, 2418. doi: 10.1039/C6EE01160H
57	Workman M. J. ; Serov A. ; Tsui L. k. ; Atanassov P. ; Artyushkova K. ACS Energy Lett. 2017, 2, 1489. doi: 10.1021/acsenergylett.7b00391
58	Yang X. D. ; Chen C. ; Zhou Z. Y. ; Sun S. G. Acta Phys. -Chim. Sin. 2019, 35, 472.
	杨晓冬; 陈驰; 周志有; 孙世刚; 物理化学学报, 2019, 35, 472. doi: 10.3866/PKU.WHXB201806131
59	Li Z. ; Wei L. ; Jiang W. J. ; Hu Z. ; Luo H. ; Zhao W. ; Xu T. ; Wu W. ; Wu M. ; Hu J. S. Appl. Catal., B 2019, 251, 240. doi: 10.1016/j.apcatb.2019.03.046
60	Xiao M. L. ; Chen Y. T. ; Zhu J. B. ; Zhang H. ; Zhao X. ; Gao L. Q. ; Wang X. ; Zhao J. ; Ge J. J. ; Jiang Z. ; et al J. Am. Chem. Soc. 2019, 141 doi: 10.1021/jacs.9b08362
61	Kramm U. I. ; Herranz J. ; Larouche N. ; Arruda T. M. ; Lefèvre M. ; Jaouen F. ; Bogdanoff P. ; Fiechter S. ; Abs-Wurmbach I. ; Mukerjee S. ; et al Phys. Chem. Chem. Phys. 2012, 14, 11673. doi: 10.1039/C2CP41957B
62	Kramm U. I. ; Lefèvre M. ; Larouche N. ; Schmeisser D. ; Dodelet J. P. J. Am. Chem. Soc. 2014, 136, 978. doi: 10.1021/ja410076f
63	Jaouen F. ; Lefèvre M. ; Dodelet J. P. ; Cai M. J. Phys. Chem. B 2006, 110, 5553. doi: 10.1021/jp057135h
64	Lefèvre M. ; Proietti E. ; Jaouen F. ; Dodelet J. P. Science 2009, 324, 71. doi: 10.1126/science.1170051
65	Zhao L. ; Zhang Y. ; Huang L. B. ; Liu X. Z. ; Zhang Q. H. ; He C. ; Wu Z. Y. ; Zhang L. J. ; Wu J. P. ; Yang W. L. ; et al Nat. Commun. 2019, 10, 1278. doi: 10.1038/s41467-019-09290-y
66	Qu Y. T. ; Wang L. G. ; Li Z. J. ; Li P. ; Zhang Q. H. ; Lin Y. ; Zhou F. Y. ; Wang H. J. ; Yang Z. K. ; Hu Y. D. ; et al Adv. Mater. 2019, 31, 1904496. doi: 10.1002/adma.201904496
67	Zion N. ; Cullen D. A. ; Zelenay P. ; Elbaz L. Angew. Chem. Int. Ed. 2020, 59, 2483. doi: 10.1002/anie.201913521
68	Zhang Y. ; Ma Y. L. ; Chen Y. Y. ; Zhao L. ; Huang L. B. ; Luo H. ; Jiang W. J. ; Zhang X. ; Niu S. ; Gao D. J. ; et al ACS Appl. Mat. Interfaces 2017, 9, 36857. doi: 10.1021/acsami.7b11748
69	Lee S. H. ; Kim J. ; Chung D. Y. ; Yoo J. M. ; Lee H. S. ; Kim M. J. ; Mun B. S. ; Kwon S. G. ; Sung Y. E. ; Hyeon T. J. Am. Chem. Soc. 2019, 141, 2035. doi: 10.1021/jacs.8b11129
70	Gupta S. ; Tryk D. ; Bae I. ; Aldred W. ; Yeager E. J. Appl. Electrochem. 1989, 19, 19. doi: 10.1007/BF01039385
71	Rojas-Carbonell S. ; Artyushkova K. ; Serov A. ; Santoro C. ; Matanovic I. ; Atanassov P. ACS Catal. 2018, 8, 3041. doi: 10.1021/acscatal.7b03991
72	Li Z. ; Sun H. ; Wei L. ; Jiang W. J. ; Wu M. ; Hu J. S. ACS Appl. Mat. Interfaces 2017, 9, 5272. doi: 10.1021/acsami.6b15154
73	Amiinu I. S. ; Liu X. ; Pu Z. ; Li W. ; Li Q. ; Zhang J. ; Tang H. ; Zhang H. ; Mu S. Adv. Funct. Mater. 2018, 28, 1704638. doi: 10.1002/adfm.201704638
74	Luo H. ; Jiang W. J. ; Niu S. ; Zhang X. ; Zhang Y. ; Yuan L. P. ; He C. ; Hu J. S. Small 2020, 16, 2001171. doi: 10.1002/smll.202001171
75	He Y. H. ; Guo H. ; Hwang S. ; Yang X. X. ; He Z. Z. ; Braaten J. ; Karakalos S. ; Shan W. T. ; Wang M. Y. ; Zhou H. ; et al Adv. Mater. 2020, 32, 2003577. doi: 10.1002/adma.202003577
76	Banham D. ; Choi J. Y. ; Kishimoto T. ; Ye S. Y. Adv. Mater. 2019, 31, 1804846. doi: 10.1002/adma.201804846
77	Stariha S. ; Artyushkova K. ; Serov A. ; Atanassov P. Int. J. Hydrogen Energy 2015, 40, 14676. doi: 10.1016/j.ijhydene.2015.05.185
78	Yin X. ; Lin L. ; Chung H. T. ; Babu S. K. ; Martinez U. ; Purdy G. M. ; Zelenay P. ECS Trans. 2017, 77, 1273. doi: 10.1149/07711.1273ecst
79	Malko D. ; Lopes T. ; Ticianelli E. A. ; Kucernak A. J. Power Sources 2016, 323, 189. doi: 10.1016/j.jpowsour.2016.05.035
80	Banham D. ; Kishimoto T. ; Sato T. ; Kobayashi Y. ; Narizuka K. ; Ozaki J. i. ; Zhou Y. J. ; Marquez E. ; Bai K. ; Ye S. Y. J. Power Sources 2017, 344, 39. doi: 10.1016/j.jpowsour.2017.01.086
81	Banham D. ; Kishimoto T. ; Zhou Y. J. ; Sato T. ; Bai K. ; Ozaki J. i. ; Imashiro Y. ; Ye S. Y. Sci. Adv. 2018, 4, eaar7180. doi: 10.1126/sciadv.aar7180
82	Komini Babu S. ; Chung H. T. ; Zelenay P. ; Litster S. ACS Appl. Mat. Interfaces 2016, 8, 32764. doi: 10.1021/acsami.6b08844
83	Uddin A. ; Dunsmore L. ; Zhang H. G. ; Hu L. M. ; Wu G. ; Litster S. ACS Appl. Mat. Interfaces 2020, 12, 2216. doi: 10.1021/acsami.9b13945
84	Liu J. J. ; Talarposhti M. R. ; Asset T. ; Sabarirajan D. C. ; Parkinson D. Y. ; Atanassov P. ; Zenyuk I. V. ACS Appl. Energy Mater. 2019, 2, 3542. doi: 10.1021/acsaem.9b00292
85	Osmieri L. ; Wang G. X. ; Cetinbas F. C. ; Khandavalli S. ; Park J. ; Medina S. ; Mauger S. A. ; Ulsh M. ; Pylypenko S. ; Myers D. J. ; et al Nano Energy 2020, 75, 104943. doi: 10.1016/j.nanoen.2020.104943
86	Osmieri L. ; Mauger S. ; Ulsh M. ; Neyerlin K. C. ; Bender G. J. Power Sources 2020, 452, 227829. doi: 10.1016/j.jpowsour.2020.227829
87	He Y. H. ; Liu S. W. ; Priest C. ; Shi Q. R. ; Wu G. Chem. Soc. Rev. 2020, 49, 3484. doi: 10.1039/C9CS00903E
88	Chenitz R. ; Kramm U. I. ; Lefèvre M. ; Glibin V. ; Zhang G. X. ; Sun S. H. ; Dodelet J. P. Energy Environ. Sci. 2018, 11, 365. doi: 10.1039/C7EE02302B
89	Zhang H. G. ; Hwang S. ; Wang M. Y. ; Feng Z. X. ; Karakalos S. ; Luo L. L. ; Qiao Z. ; Xie X. H. ; Wang C. M. ; Su D. ; et al J. Am. Chem. Soc. 2017, 139, 14143. doi: 10.1021/jacs.7b06514
90	Zitolo A. ; Goellner V. ; Armel V. ; Sougrati M. T. ; Mineva T. ; Stievano L. ; Fonda E. ; Jaouen F. Nat. Mater. 2015, 14, 937. doi: 10.1038/nmat4367
91	Makharia R. ; Mathias M. F. ; Baker D. R. J. Electrochem. Soc. 2005, 152, 189. doi: 10.1149/1.1888367
92	Choi C. H. ; Baldizzone C. ; Polymeros G. ; Pizzutilo E. ; Kasian O. ; Schuppert A. K. ; Ranjbar Sahraie N. ; Sougrati M. T. ; Mayrhofer K. J. J. ; Jaouen F. ACS Catal. 2016, 6, 3136. doi: 10.1021/acscatal.6b00643
93	Liu G. ; Li X. G. ; Popov B. ECS Trans. 2009, 25, 1251. doi: 10.1149/1.3210680
94	Herranz J. ; Jaouen F. ; Lefèvre M. ; Kramm U. I. ; Proietti E. ; Dodelet J. P. ; Bogdanoff P. ; Fiechter S. ; Abs-Wurmbach I. ; Bertrand P. ; et al J. Phys. Chem. C 2011, 115, 16087. doi: 10.1021/jp2042526
95	Strmcnik D. ; Escudero-Escribano M. ; Kodama K. ; Stamenkovic V. R. ; Cuesta A. ; Marković N. M. Nat. Chem. 2010, 2, 880. doi: 10.1038/nchem.771
96	Goellner V. ; Baldizzone C. ; Schuppert A. ; Sougrati M. T. ; Mayrhofer K. ; Jaouen F. Phys. Chem. Chem. Phys. 2014, 16, 18454. doi: 10.1039/C4CP02882A
97	Meyers J. P. ; Darling R. M. J. Electrochem. Soc. 2006, 153, A1432. doi: 10.1149/1.2203811
98	Wang Y. C. ; Zhu P. F. ; Yang H. ; Huang L. ; Wu Q. H. ; Rauf M. ; Zhang J. Y. ; Dong J. ; Wang K. ; Zhou Z. Y. ; et al ChemElectroChem 2018, 5, 1914. doi: 10.1002/celc.201700939
99	Choi C. H. ; Baldizzone C. ; Grote J. P. ; Schuppert A. K. ; Jaouen F. ; Mayrhofer K. J. J. Angew. Chem. Int. Ed. 2015, 54, 12753. doi: 10.1002/anie.201504903
100	Schulenburg H. ; Stankov S. ; Schünemann V. ; Radnik J. ; Dorbandt I. ; Fiechter S. ; Bogdanoff P. ; Tributsch H. J. Phys. Chem. B 2003, 107, 9034. doi: 10.1021/jp030349j
101	Choi C. H. ; Lim H. K. ; Chung M. W. ; Chon G. ; Ranjbar Sahraie N. ; Altin A. ; Sougrati M. T. ; Stievano L. ; Oh H. S. ; Park E. S. ; et al Energy Environ. Sci. 2018, 11, 3176. doi: 10.1039/C8EE01855C
102	Wu G. ; More K. L. ; Xu P. ; Wang H. ; Ferrandon M. ; Kropf A. J. ; Myers D. J. ; Ma S. G. ; Johnston C. M. ; Zelenay P. Chem. Commun. 2013, 49, 3291. doi: 10.1039/C3CC39121C
103	Xia D. S. ; Yang X. ; Xie L. ; Wei Y. P. ; Jiang W. L. ; Dou M. ; Li X. N. ; Li J. ; Gan L. ; Kang F. Y. Adv. Funct. Mater. 2019, 29, 1906174. doi: 10.1002/adfm.201906174
104	Zhang Z. P. ; Sun J. T. ; Wang F. ; Dai L. M. Angew. Chem. Int. Ed. 2018, 57, 9038. doi: 10.1002/anie.201804958
105	Wei H. W. ; Su X. G. ; Liu J. G. ; Tian J. ; Wang Z. W. ; Sun K. ; Rui Z. Y. ; Yang W. W. ; Zou Z. G. Electrochem. Commun. 2018, 88, 19. doi: 10.1016/j.elecom.2018.01.011
106	Zhang G. X. ; Chenitz R. ; Lefèvre M. ; Sun S. H. ; Dodelet J. P. Nano Energy 2016, 29, 111. doi: 10.1016/j.nanoen.2016.02.038
107	Choi J. Y. ; Yang L. J. ; Kishimoto T. ; Fu X. G. ; Ye S. Y. ; Chen Z. W. ; Banham D. Energy Environ. Sci. 2017, 10, 296. doi: 10.1039/C6EE03005J
108	Mittermeier T. ; Weiß A. ; Hasché F. ; Hübner G. ; Gasteiger H. A. J. Electrochem. Soc. 2016, 164, F127. doi: 10.1149/2.1061702jes
109	Yang L. J. ; Larouche N. ; Chenitz R. ; Zhang G. ; Lefèvre M. ; Dodelet J. P. Electrochim. Acta 2015, 159, 184. doi: 10.1016/j.electacta.2015.01.201

Type of fuel cell	Operation temperature/℃	General power density/(mW·cm^-2)	System lifetime/h	Start-up time
PEMFC	50–80	350	2500	Seconds
PAFC	160–220	200	> 40000 *	Few minutes
MCFC	600–700	100	> 40000 *	Few minutes
SOFC	800–1000	240	> 40000 *	Few minutes
AFC	60–90	100–200	500–1000	Seconds

Catalysts	Operation condition	Operation temperature/K	Catalyst loading/(mg cm^-2)	P_max/(mW·cm^-2)	Current density at 0.8 V/(mA·cm^-2)
Co-N-C@F127 ²⁷	100 kPa H₂-O₂	353	4	870	30 at 0.8 V *
(CM+PANI)-Fe-C ²⁹	200 kPa H₂-O₂	353	4.0	940	240 at 0.8 V *
SA-Fe/NG ³⁰	250 kPa H₂-O₂	353	2	823	200 at 0.8 V *
Fe/N/C-SCN ³¹	200 kPa H₂-O₂	353	4.0	1030	310 at 0.8 V *
ZIF'-FA-CNT-p ³²	100 kPa H₂-O₂	353	4.5	820	250 at 0.8 V
20Co-NC-1100 ³³	206.8 kPa H₂-O₂	353	4.0	560	50 at 0.8 V
Fe/TPTZ/ZIF-8 ³⁴	100 kPa H₂-O₂	353	4	770 *	240 at 0.8 V *
PANI-FeCo-C ³⁵	280 kPa H₂-O₂	353	4	550	> 100 at 0.8 V *
PFeTTPP-1000 ³⁶	150 kPa H₂-O₂	353	4.1	730	100 at 0.8 V *
CNT/PC ³⁷	100 kPa H₂-O₂	353	3.05	580	160 at 0.8 V *
C-FeZIF-1.44-950 ³⁸	206.8 kPa H₂-O₂	353	1	775	210 at 0.8 V
TPI@Z8(SiO₂)-650-C ³⁹	250 kPa H₂-O₂	353	2.7	1180	560 at 0.8 V *
Fe/N/CF ⁴⁰	150 kPa H₂-O₂	353	2.0	900	250 at 0.8 V
(Fe, Co)/N-C ⁴¹	100 kPa H₂-O₂	353	0.77	850	50 at 0.8 V
C-FeHZ8@g-C₃N₄-950 ⁴²	206.8 kPa H₂-O₂	353	4	628	133 at 0.8 V *
(CM+PANI)-Fe-C ²⁹	100 kPa H₂-air	353	4	420	90 at 0.8 V
20Co-NC-1100 ³³	206.8 kPa H₂-air	353	4	280	40 at 0.8 V
Fe/TPTZ/ZIF-8 ³⁴	100 kPa H₂-air	353	4	300	125 at 0.8 V *
FePhen@MOF-ArNH3 ⁴³	250 kPa H₂-air	353	3	380	> 100 at 0.8 V *
Fe-N-C-Phen-PANI ⁴⁴	137.9 kPa H₂-air	353	4	380	120 at 0.8 V
Fe-MBZ ⁴⁵	400 kPa H₂-air	353	4	335	77 at 0.8 V
