Selective Hydrogenation of 5-(Hydroxymethyl)furfural to 5-Methylfurfural by Exploiting the Synergy between Steric Hindrance and Hydrogen Spillover

Shaopeng Li¹^,²^,³, Jing Du³, Bin Zhang¹, Yanzhen Liu¹, Qingqing Mei¹, Qinglei Meng¹^,³, Minghua Dong¹^,², Juan Du¹, Zhijuan Zhao¹, Lirong Zheng⁴, Buxing Han¹^,²^,⁵, Meiting Zhao³^,*(), Huizhen Liu¹^,²^,⁵^,*()

¹ Beijing National Laboratory for Molecular Sciences, CAS Key Laboratory of Colloid and Interface and Thermodynamics, Institute of Chemistry, Chinese Academy of Sciences, Beijing 100190, China
² School of Chemical Sciences, University of Chinese Academy of Sciences, Beijing 100049, China
³ Institute of Molecular Aggregation Science, Tianjin University, Tianjin 300072, China
⁴ Institute of High Energy Physics, Chinese Academy of Sciences, Beijing 100049, China
⁵ Physical Science Laboratory, Huairou National Comprehensive Science Center, Beijing 101407, China

Received:2022-06-14 Accepted:2022-07-21 Published:2022-07-29
Contact: Meiting Zhao,Huizhen Liu E-mail:mtzhao@tju.edu.cn;liuhz@iccas.ac.cn
About author:Huizhen Liu, E-mail: liuhz@iccas.ac.cn
Meiting Zhao, E-mail: mtzhao@tju.edu.cn
Supported by:
the National Key Research and Development Program of China(2017YFA0403003);the National Key Research and Development Program of China(2017YFA0403101);National Natural Science Foundation of China(21871277);National Natural Science Foundation of China(21603235);National Natural Science Foundation of China(21403248);National Natural Science Foundation of China(21905195);China Postdoctoral Science Foundation(2021M702435);Beijing Municipal Science & Technology Commission(Z191100007219009)

Abstract

Abstract:

Selective hydrogenation is a vital class of reaction. Various unsaturated functional groups in organic compounds, such as aromatic rings, alkynyl (C≡C), carbonyl (C＝O), nitro (-NO₂), and alkenyl (C＝C) groups, are typical targets in selective hydrogenation. Therefore, selectivity is a key indicator of the efficiency of a designed hydrogenation reaction. 5-(Hydroxymethyl)furfural (HMF) is an important platform compound in the context of biomass conversion, and recently, the hydrogenation of HMF to produce fuels and other valuable chemicals has received significant attention. Controlling the selectivity of HMF hydrogenation is paramount because of the different reducible functional groups (C＝O, C-OH, and C＝C) in HMF. Moreover, the exploration of new routes for hydrogenating HMF to valuable chemicals is becoming attractive. 5-Methylfurfural (MF) is also an important organic compound; thus, the selective hydrogenation of HMF to MF is an essential synthetic route. However, this reaction has challenging thermodynamic and kinetic aspects, making it difficult to realize. Herein, we propose a strategy to design a highly efficient catalytic system for selective hydrogenation by exploiting the synergy between steric hindrance and hydrogen spillover. The design and preparation of the Pt@PVP/Nb₂O₅ catalyst (PVP = polyvinyl pyrrolidone; Nb₂O₅ = niobium(V) oxide) were also conducted. Surprisingly, HMF could be converted to MF with 92% selectivity at 100% HMF conversion. The reaction pathway was revealed through the combination of control experiments and density functional theory calculations. Although PVP blocked HMF from accessing the surface of Pt, hydrogen (H₂) could be activated on the surface of Pt due to its small molecular size, and the activated H₂ could migrate to the surface of Nb₂O₅ through a phenomenon called H₂ spillover. The Lewis acidic surface of Nb₂O₅ could not adsorb the C＝O group but could adsorb and activate the C-OH group of HMF; therefore, when HMF was adsorbed on Nb₂O₅, the C-OH groups were hydrogenated by the spilled over H₂ to form MF. The high selectivity of this reaction was realized because of the unique combination of steric effects, hydrogen spillover, and tuning of the electronic states of the Pt and Nb₂O₅ surfaces. This new route for producing MF has great potential for practical application owing to its discovered advantages. We believe that this novel strategy can be used to design catalysts for other selective hydrogenation reactions. Furthermore, this study demonstrates a significant breakthrough in selective hydrogenation, which will be of interest to researchers working on the utilization of biomass, organic synthesis, catalysis, and other related fields.

Key words: Biomass, 5-Hydroxymethylfurfural, Selective hydrodeoxygenation, Steric hindrance, Hydrogen spillover

Shaopeng Li, Jing Du, Bin Zhang, Yanzhen Liu, Qingqing Mei, Qinglei Meng, Minghua Dong, Juan Du, Zhijuan Zhao, Lirong Zheng, Buxing Han, Meiting Zhao, Huizhen Liu. Selective Hydrogenation of 5-(Hydroxymethyl)furfural to 5-Methylfurfural by Exploiting the Synergy between Steric Hindrance and Hydrogen Spillover[J]. Acta Phys. -Chim. Sin. 2022, 38(10), 2206019. doi: 10.3866/PKU.WHXB202206019

Figures/Tables 8

References 33

1	Ragauskas, A. J.; Williams, C. K.; Davison, B. H.; Britovsek, G.; Cairney, J.; Eckert, C. A.; Frederick, W. J., Jr.; Hallett, J. P.; Leak, D. J.; Liotta, C. L.; et al. Science 2006, 311, 484. doi: 10.1126/science.1114736
2	Román-Leshkov, Y.; Barrett, C. J.; Liu, Z. Y.; Dumesic, J. A. Nature 2007, 447, 982. doi: 10.1038/nature05923
3	Putten, R. J.; Waal, J. C.; Jong, E.; Rasrendra, C. B.; Heeres, H. J.; Vries, J. G. Chem. Rev. 2013, 113, 1499. doi: 10.1021/cr300182k
4	Vriamont, C.; Haynes, T.; Cague-Murphy, E. M.; Pennetreau, F.; Riant, O.; Hermans, S. J. Catal. 2015, 329, 389. doi: 10.1016/j.jcat.2015.06.003
5	Fang, R. Q.; Luque, R.; Li, Y. W. Green Chem. 2017, 19, 647. doi: 10.1039/c6gc02018f
6	Besson, M.; Gallezot, P.; Pinel, C. Chem. Rev. 2014, 114, 1827. doi: 10.1021/cr4002269
7	Luo, J.; Yun, H.; Mironenko, A. V.; Goulas, K.; Lee, J. D.; Monai, M.; Wang, C.; Vorotnikov, V.; Murray, C. B.; Vlachos, D. G.; et al. ACS Catal. 2016, 6, 4095. doi: 10.1021/acscatal.6b00750
8	Thananatthanachon, T.; Rauchfuss, T. B. Angew. Chem. Int. Edit. 2010, 49, 6616. doi: 10.1002/anie.201002267
9	Nilges, P.; Schroder, U. Energ. Environ. Sci. 2013, 6, 2925. doi: 10.1039/c3ee41857j
10	Yang, P. P.; Cui, Q. Q.; Zu, Y. H.; Liu, X. H.; Lu, G. Z.; Wang, Y. Q. Catal. Commun. 2015, 66, 55. doi: 10.1016/j.catcom.2015.02.014
11	Wang, G. H.; Hilgert, J.; Richter, F. H.; Wang, F.; Bongard, H. J.; Spliethoff, B.; Weidenthaler, C.; Schüth, F. Nat. Mater. 2014, 13, 294. doi: 10.1038/nmat3872
12	Alamillo, R.; Tucker, M.; Chia, M.; Pagan-Torres, Y.; Dumesic, J. Green Chem. 2012, 14, 1413. doi: 10.1039/c2gc35039d
13	Nakagawa, Y.; Tomishige, K. Catal. Commun. 2010, 12, 154. doi: 10.1016/j.catcom.2010.09.003
14	Liu, F.; Audemar, M.; Vigier, K. D.; Clacens, J. M.; De, C. F.; Jerome, F. Green Chem. 2014, 16, 4110. doi: 10.1039/c4gc01158a
15	Jung, M. E.; Im, G-Y. J. Org. Chem. 2009, 74, 8739. doi: 10.1021/jo902029x
16	Wang, W.; Zhao, X. M.; Wang, J. L.; Geng, X.; Gong, J. F.; Hao, X. Q.; Song, M. P. Tetrahedron Lett. 2014, 55, 3192. doi: 10.1016/j.tetlet.2014.04.020
17	Michail, K.; Matzi, V.; Maier, A.; Herwig, R.; Greilberger, J.; Juan, H.; Kunert, O.; Wintersteiger, R. Anal. Bioanal. Chem. 2007, 387, 2801. doi: 10.1007/s00216-007-1121-6
18	Tradtrantip, L.; Sonawane, N. D.; Namkung, W.; Verkman, A. S. J. Med. Chem. 2009, 52, 6447. doi: 10.1021/jm9009873
19	Huber, G. W.; Iborra, S.; Corma, A. Chem. Rev. 2006, 106, 4044. doi: 10.1021/cr068360d
20	Corma, A.; de la Torre, O.; Renz, M.; Villandier, N. Angew. Chem. Int. Edit. 2011, 50, 2375. doi: 10.1002/anie.201007508
21	Mascal, M.; Nikitin, E. B. Angew. Chem. Int. Edit. 2008, 47, 7924. doi: 10.1002/anie.200801594
22	Li, S.; Dong, M.; Yang, J.; Cheng, X.; Shen, X.; Liu, S.; Wang, Z.-Q.; Gong, X.-Q.; Liu, H.; Han, B. Nat. Commun. 2021, 12, 584. doi: 10.1038/s41467-020-20878-7
23	Shao, Y.; Xia, Q. N.; Dong, L.; Liu, X. H.; Han, X.; Parker, S. F.; Cheng, Y. Q.; Daemen, L. L.; Ramirez-Cuesta, A. J.; Yang, S. H.; et al. Nat. Commun. 2017, 8, 16104. doi: 10.1038/ncomms16104
24	Chen, G. X.; Xu, C. F.; Huang, X. Q.; Ye, J. Y.; Gu, L.; Li, G.; Tang, Z. C.; Wu, B. H.; Yang, H. Y.; Zhao, Z. P.; et al. Nat. Mater. 2016, 15, 564. doi: 10.1038/NMAT4555
25	Tamura, M.; Tomishige, K. Angew. Chem. Int. Edit. 2015, 54, 864. doi: 10.1002/anie.201409601
26	Badri, A.; Binet, C.; Lavalley, J. C. J. Chem. Soc. Faraday T. 1997, 93, 1159. doi: 10.1039/a606628c
27	Xia, Q. N.; Chen, Z. J.; Shao, Y.; Gong, X. Q.; Wang, H. F.; Liu, X. H.; Parker, S. F.; Han, X.; Yang, S. H.; Wang, Y. Q. Nat. Commun. 2016, 7, 11162. doi: 10.1038/ncomms11162
28	Xia, Q. N.; Cuan, Q.; Liu, X. H.; Gong, X. Q.; Lu, G. Z.; Wang, Y. Q. Angew. Chem. Int. Edit. 2014, 53, 9755. doi: 10.1002/anie.201403440
29	Chen, H. L.; Yang, H.; Briker, Y.; Fairbridge, C.; Omotoso, O.; Ding, L. H.; Zheng, Y.; Ring, Z. Catal. Today 2007, 125, 256. doi: 10.1016/j.cattod.2007.01.024
30	Karim, W.; Spreafico, C.; Kleibert, A.; Gobrecht, J.; VandeVondele, J.; Ekinci, Y.; van Bokhoven, J. A. Nature 2017, 541, 68. doi: 10.1038/nature20782
31	Sodesawa, T.; Sato, S.; Nozaki, F. Stud. Surf. Sci. Catal. 1993, 77, 401. doi: 10.1016/S0167-2991(08)63221-8
32	Liu, R. X.; Yu, Y. C.; Yoshida, K.; Li, G. M.; Jiang, H. X.; Zhang, M. H.; Zhao, F. Y.; Fujita, S.; Arai, M. J. Catal. 2010, 269, 191. doi: 10.1016/j.jcat.2009.11.007
33	Ma, D.; Lu, S.; Liu, X.; Guo, Y.; Wang, Y. Chin. J. Catal. 2019, 40, 609. doi: 10.1016/S1872-2067(19)63317-6


Entry	Catalyst	Time/h	Conv./%	Sel./%
Entry	Catalyst	Time/h	Conv./%	1	2	3	4
1	Pt@PVP/Nb₂O₅	24	> 99	92	–	–	–
2	Nb₂O₅	12	7	63	–	–	–
3	Pt/Nb₂O₅	3.0	80	12	60	17	0
4	Pt@PVP	12	16	37	45	-	–
5 ^b	Pt/C-com.	0.5	23	–	–	–	90
6	Pt@PVP/C	12	56	32	–	–	57
7	Pt@PVP/TiO₂	12	48	25	64	9	–


Entry	Cat./mg		Time/h	Conv./%	Sel./%
Entry	1	2	Time/h	Conv./%	1	2	3	4
1	40	–	1.5	0.6	61	–	–	–
2	–	10	1.5	65	trace	10	–	83
3	40	10	1.5	32	20	–	–	67
4	40	5	1.0	28	24	–	–	56
5	40	3	0.5	8	43	–	–	51
6	–	3	0.5	23	–	90	–	–
